Dual-beam X-ray inspection machine for cans, jars, bottles X ray machine for can food
*Dual-beam X-ray inspection system Introduction:
Dual-beam X-ray inspection system are with software specifically tailored to inspect objects in all regions of cans, tins and bottles.
Dual-beam X-ray inspection system can achieve inspection in double visual angles and avoid missing inspection of blind area.
Dual-beam X-ray inspection system can achieve better inspection ratio for irregular fragments
Dual-beam X-ray inspection system has intelligent zoning to ensure optimal sensitivity for different areas.
*Parameter of Dual-beam X-ray inspection system
| Model |
TXR-2080BDX |
| X-ray Tube |
MAX. 120kV, 480W(two for each) |
| Inspection Width |
160mm |
| Inspection Height |
260mm |
| Best Inspection Sensitivity |
Stainless steel ball Φ0.5mm Stainless steel wire Φ0.3*2mm Ceramic/Ceramic ball Φ2.0mm |
| Conveyor Speed |
10-60m/min |
| O/S |
Windows 7 |
| Protection Method |
Protective tunnel |
| X-ray Leakage |
< 0.5 μSv/h |
| IP Rate |
IP54 (Standard), IP65 (Optional) |
| Working Environment |
Temperature: -10~40℃ |
|
Humidity:30~90%, no dew |
|
| Cooling Method |
Industrial air conditioning |
| Rejecter Mode |
Push rejecter |
| Air Pressure |
0.8Mpa |
| Power Supply |
4kW |
| Main Material |
SUS304 |
| Surface Treatment |
Mirror polished/Sand blasted |
*Note
The technical parameter above namely is the result of sensitivity by inspecting only the test sample on the belt. The actual sensitivity would be affected according to the products being inspected.
